Failsafe closed pneumatic vane actuator for 1/4 turn valve Serie A PALETTE

Many connections and options available, see our Product sheet.

DIMENSIONS			TYPE	Casing material	ISO 5211 connection	Springs torque bar	Opening torque @ 5.62 bar	Reference
Hmm	Amm	Bmm			ISO 5211	Start - endN.m	Start - endN.m
117	113	102	033F120	Zamak + epoxy	F03-F05 / 11	10,3 - 8,7	10,6 - 9,0	2007-64C
138	137	117	053F120	Zamak + epoxy	F04-F05 / 14	20,9 - 17,5	21,5 - 18,1	2007-65C
128	178	182	073F120	Aluminium + epoxy	F05-F07 / 17	50,8 - 42,4	52,6 - 44,2	2007-66C
187	208	197	083F120	Aluminium + epoxy	F07 / 17	81,3 - 65,5	89,5 - 73,7	2007-71S
212	227	218	093F120	Aluminium + epoxy	F07-F10 / 22	104,0 - 93,8	105,2 - 95,0	2007-67C
232	230	265	103F120	Aluminium + epoxy	F10 / 22	164,0 - 143,0	182,0 - 161,0	2007-52P
250	294	248	123F120	Aluminium + epoxy	F10 / 22	238,0 - 204,0	242,0 - 208,0	2007-68C
284	380	417	143F120-4900	Aluminium + epoxy	F12 / 27	529,0 - 447,0	633,0 - 551,0	2007-69C
407	433	503	153F120	Aluminium + epoxy	F14 / 36	962,0 - 790,0	1018,0 - 846,0	2007-72C
564	530	486	163F120	Aluminium + epoxy	F14 / 36	1321,0 - 1081,0	1339,0 - 1099,0	2007-70C
