ISO 5211 actuation kit (bracket, drive, screws) for butterfly valve series 3600/3602, 3610, 3700/3702, 3800/3802

ISO 5211 actuation kit (bracket, drive, screws) for butterfly valve series 3600/3602, 3610, 3700/3702, 3800/3802 Serie KIT

Many connections and options available, see our Product sheet.

DIMENSIONS ISO 5211 connection 45° square male Reference
DNmm DNinch Lmm Hmm Amm
50 2'' - 127.5 15 F05/F07 14 KIT0580
50 2'' - 127.5 15 F05/F07 17 KIT0581
50 2'' - 127.5 15 F05/F07 22 KIT0582
50 2'' - 127.5 15 F05/F07 27 KIT0585
65 2''1/2 - 133 15 F05/F07 14 KIT0580
65 2''1/2 - 133 15 F05/F07 17 KIT0581
65 2''1/2 - 133 15 F05/F07 22 KIT0582
65 2''1/2 - 133 15 F05/F07 27 KIT0585
80 3'' - 142.5 15 F05/F07 14 KIT0580
80 3'' - 142.5 15 F05/F07 17 KIT0581
80 3'' - 142.5 15 F05/F07 22 KIT0582
80 3'' - 142.5 15 F05/F07 27 KIT0585
100 4'' - 157 15 F05/F07 14 KIT0580
100 4'' - 157 15 F05/F07 17 KIT0581
100 4'' - 157 15 F05/F07 22 KIT0582
100 4'' - 157 15 F05/F07 27 KIT0585
125 5'' 100 265 24 F05/F07 17 KIT0039
125 5'' 100 265 24 F05/F07 22 KIT0083
125 5'' 140 270 24 F10/F12 22 KIT0017
125 5'' 140 270 29 F10/F12 36 KIT0409
150 6" - 195 17 F07/F10 17 KIT0550
150 6" - 195 17 F07/F10 22 KIT0549
150 6" - 195 27 F07/F10 27 KIT0554
200 8'' 180 279 24 F10/F12 22 KIT0038
200 8'' 180 278 29 F10/F12 27 KIT0163
200 8'' 180 279 36 F10/F12 36 KIT0166
250 10'' 180 317 24 F10/F12 22 KIT0038
250 10'' 180 317 29 F10/F12 27 KIT0163
250 10'' 180 317 29 F10/F12 36 KIT0182
250 10" 180 317 36 F14/F16 36 KIT0115
250 10'' 180 317 46 F14/F16 46 KIT0141
300 12'' 180 363 27 F10/F12 27 KIT0407
300 12'' 180 363 36 F10/F12 36 KIT0193
300 12'' 180 364 36 F14/F16 36 KIT0032
300 12'' 180 364 46 F14/F16 46 KIT0140
350 14'' 180 380 27 F10/F12 27 KIT0407
350 14'' 180 380 36 F10/F12 36 KIT0193
350 14'' 180 380 36 F14/F16 36 KIT0032
350 14'' 180 380 46 F14/F16 46 KIT0140
400 16'' 300 493 36 F14/F16 36 KIT0142
400 16'' 300 493 46 F14/F16 46 KIT0167
450 18'' 300 495 36 F14/F16 36 KIT0417
450 18'' 300 495 46 F14/F16 46 KIT0169
500 20'' 300 535 36 F14/F16 36 KIT0417
500 20'' 300 535 46 F14/F16 46 KIT0169

(*) To order a butterfly valve ready for actuation, please add the code ACTUREADY after the code of the valve. For example 3600-09WWE + ACTUREADY : - for DN50 to DN100 + DN150: the handled is removed. - for DN125, DN200 and higher : the handled or the gearbox is removed, the face is machined and drilled To actuate a type 3610 butterfly valve, please contact us.
